Shopify OS 2.0 架构:JSON 模板与 Sections

摘要

OS 2.0 是 Shopify 历史上最大的架构升级!深度解析 JSON 模板取代 Liquid 模板的底层逻辑。掌握 Sections Everywhere(随处可用区块)的开发思想。

1. 核心底层逻辑

在旧版(Vintage)主题时代,只有首页(index.liquid)支持自由拖拽区块(Sections)。产品页、博客页的排版是被写死在代码里的,商家想加个图文介绍,只能求助程序员。

Shopify OS 2.0 架构:JSON 模板与 Sections 总览图
先看这张总览图,再对照正文里的步骤、字段和检查项操作。

核心逻辑是:数据与视图的系统解耦。

Online Store 2.0(OS 2.0)是一场革命。它将所有页面的模板从 .liquid 变成了 .json。JSON 文件只负责记录“这个页面有哪些 Section,它们的顺序是什么,商家填了什么数据”。而真正的 HTML 渲染逻辑,全部下放到了独立的 Section 文件中。这就实现了 Sections Everywhere(随处可用区块),让商家在任何页面都能像搭积木一样自由排版。

2. Step-by-Step 操作指南

核心机制 1:理解 JSON 模板的结构

操作路径打开 templates/product.json

  1. 一个标准的 JSON 模板包含三个核心对象:sections, order, wrapper
  2. sections:定义了页面上所有的区块实例。每个实例都有一个唯一的 ID(如 "main"),并指定了它使用的是哪个 Section 代码文件(type: "main-product"),以及商家在后台配置的数据(settings)。
  3. order:一个数组,决定了这些 Sections 在页面上从上到下的渲染顺序(如 ["main", "recommendations", "reviews"])。

核心机制 2:创建多套页面模板 (Multiple Templates)

操作路径Shopify后台 -> 在线商店 -> 模板 -> 自定义 -> 顶部下拉菜单

  1. 在 OS 2.0 中,你可以为同一种页面类型创建无数个不同的排版。
  2. 例如,创建一个 product.vip.json。在这个模板里,你可以添加一个专属的“VIP 会员说明” Section。
  3. 然后在 Shopify 后台的产品管理页面,将特定产品的“模板后缀(Theme template)”指定为 vip。这样,普通产品和 VIP 产品就能展示完全不同的页面结构。

核心机制 3:Section 的独立渲染 (Section Rendering API)

操作路径前端 Ajax 请求

  1. OS 2.0 允许你通过 API 单独请求某个 Section 的 HTML,而不需要刷新整个页面。
  2. 例如,在实现“点击加载更多”时,你可以向 Shopify 发送请求:/collections/all?section_id=product-grid&page=2
  3. Shopify 服务器只会返回 product-grid.liquid 这个 Section 渲染后的 HTML 代码。前端拿到代码后直接插入 DOM,明显提升了 Ajax 交互的性能。

3. 2026年最新大坑与规避方法

大坑一:在 JSON 模板中写注释或尾随逗号

规避方法:JSON 是一种非常严格的数据交换格式。很多前端习惯了在 JavaScript 的对象里写 // 这是一个注释,或者在数组的最后一个元素后面顺手加一个逗号 ,在 Shopify 的 .json 模板文件中,绝对不允许出现任何注释和尾随逗号! 一旦出现语法错误,整个页面在 Shopify 后台将直接白屏报错,商家无法进行任何操作。需要在 VS Code 中配置好 JSON 格式化工具(如 Prettier),保存时自动修复语法错误。

大坑二:手动修改 JSON 模板导致数据丢失

规避方法:如前所述,templates/*.json 文件保存的是商家在可视化编辑器里辛辛苦苦填写的真实数据(比如一段精心撰写的品牌故事,或者上传的 Banner 图片链接)。作为开发者,你永远不应该在本地手动修改这些 JSON 文件中的 settings 数据,然后再 push 到线上。 你的修改会直接覆盖商家的心血。开发者只负责在 JSON 的 sections 中注册新的模块类型,具体的数据填充需要交由商家在后台完成。

大坑三:遗留的 .liquid 模板阻碍了 Sections Everywhere

规避方法:如果你在升级一个老主题,或者从网上抄了一段旧代码,在 templates/ 目录下创建了一个 page.about.liquid。你会发现,当商家在后台编辑这个“关于我们”页面时,左侧的侧边栏根本没有“添加区块(Add Section)”的按钮!只要模板后缀是 .liquid,它就永远无法享受 OS 2.0 的自由拖拽特性。 需要将其转换为 page.about.json,并将原有的 HTML 代码提取到一个独立的 sections/main-page.liquid 中进行调用。

常见问题

学习「Shopify Online Store 2.0 核心架构解析:JSON 模板与 Sections Everywhere」前需要什么基础?

建议先熟悉 HTML、CSS、基础 JavaScript 和 Shopify 后台结构。涉及 Liquid、Section、Schema 或主题工作流的内容,可以边读边在测试主题里练习,不要直接改线上主题。

可以直接在正在使用的线上主题里操作吗?

不建议。主题开发和结构调整应先在复制主题、开发主题或本地环境中完成,确认移动端、产品页、购物车和关键模板正常后,再发布到线上主题。

修改主题前最应该备份什么?

至少保留当前主题副本,并用 Git 记录代码变化。如果文章涉及主题编辑器配置,还要注意模板 JSON 和 settings_data.json 这类配置文件是否需要同步。

遇到教程和后台界面不一致怎么办?

优先以当前 Shopify 后台、主题代码和官方文档为准。Shopify 后台和 CLI 会持续更新,旧截图可用于理解路径,但不能替代当前界面提示。

这类主题开发内容适合什么时候上线到正式店铺?

当改动已经在测试主题中完成移动端、桌面端、产品页、集合页、购物车和速度检查后,再安排上线。影响结账、价格、库存或应用兼容的改动要单独回归。
